Canon Service Tools and Supported Printers

When a Canon printer operates for a long time (approximately 2-4 years), it will eventually cause an error: Ink absorber is almost full or ink absorber is full, with error codes: 1700/1701/1702/1703, or 5B00/5B01/5B02/5B03. When a full ink absorber occurs, repairs are carried out in two stages, namely replacing or cleaning the ink absorber, followed by resetting the waste ink counter value.

There are two ways to reset a Canon printer, manually and using software (General Tool or Service Tool.) To determine what method is used to reset a Canon printer, the printer's Service Manual is the reference. Based on the Canon printer Service Manual data that we have, then we summarize in table form (see table list below), here's how to reset a Canon printer for full ink absorption error, with error code: 1700/1701/1702/1703, or 5B00/5B01/5B02/5B03.

In this post, we will discuss the Canon printer series (S, i, iP, MP, MX, MG, iX, E, G, Pro, TS) and the Service Tool used to reset the printer.

There are 3 ways to reset a Canon printer, namely

1.   Manual Method

The manual method is how to reset the Canon printer by pressing the Stop/Reset/Resume/Cancel button combination and the Power/ON button, alternately a certain number of times.

2.   General Tool

General Tool is a portable software that has several buttons that function to do: test print, print EEPROM data, maintenance, reset, etc.

3.   Service Tool

Service Tool is a portable software that has several buttons that function to do: test print, print EEPROM data, maintenance, reset, etc.

Here are three ways to reset a Canon printer for this type of malfunction "Warning: The ink absorber is almost full, or the ink absorber is full".

1. How to reset the waste ink counter value manually (Manual)

List of printers reset manually: see table below.

Step 1: Enter Service Mode
- The printer is off.
- Press and hold the Stop/Reset/Resume/Cancel button.

- Press and hold the ON/Power button.

- Release the Stop/Reset/Resume/Cancel button (the ON/Power button is still pressed)

- While holding down the ON/Power button, press the Stop/Reset/Resume/Cancel button 2/3 times (see table below), then release the ON/Power button.
- Wait a moment, the ON/Power LED will flash and light green/blue. If the ON/Power LED is green/blue and not blinking, it means that the printer has entered Service Mode, and the printer is ready to be reset.

Step 2: Reset the waste ink counter value to zero
- Press the Stop/Reset/Resume/Cancel button 4 times then press the ON/Power button 1 time. When the ON/Power button is pressed 1 time, look at the Power LED. If the Power LED flashes when the ON/Power button is pressed 1 time, it means that the reset has been successfully performed.

- Press the ON/Power button 1 time to turn off the printer, then wait about 15 seconds, then turn the printer back on. Done.

2. How to reset the waste ink counter value with the General Tool (GT)
List of printers that are reset with the General Tool: see table below.

Step 1: Enter Service Mode

- Connect the printer's USB cable to the computer.

- Disconnect the AC power cord from the power source.

- Press and hold the Power button.

- While pressing the Power button, connect the AC power cable to a power source (do not release the Power button).

- If the Power LED turns green, while holding down the Power button, press the Resume/Cancel button 2 times (see table below), then release both the Power and Resume/Cancel buttons at the same time.

- Wait a few moments, the Power LED will flash and light green. If the Power LED is green and not blinking, it means that the printer has entered Service Mode.

Step 2: Reset the waste ink counter value to zero
- Open the General Tool to start resetting the printer. See the table below for a list of printers that are reset with the General Tool (GT).

3. How to reset waste ink counter value with Service Tool (ST)

List of printers reset with the Service Tool: see table below.

Step 1: Enter Service Mode

- The printer is turned off, the printer's USB cable is connected to the computer, and the AC power cable is connected to a power source.

- Press and hold the Stop/Reset/Resume/Cancel button.

- Press and hold the ON/Power button.

- Release the Stop/Reset/Resume/Cancel button (don't release the ON/Power button)

- While holding the ON/Power button, press the Stop/Reset/Resume/Cancel button 2/3/5/6 *** times (see table list below) then release the ON/Power button.

- Wait a moment, the ON/Power LED will flash and light green/blue. If the ON/Power LED is green/blue and not blinking, it means that the printer has entered Service Mode.

***

- While holding down the ON/Power button, press the Stop/Reset/Resume/Cancel button 2 times then release the ON/Power button. Wait a while, if the ON/Power LED keeps flashing, repeat the procedure, press the Stop/Reset/Resume/Cancel button 3 times.

- While holding down the ON/Power button, press the Stop/Reset/Resume/Cancel button 5 times then release the ON/Power button. Wait a while, if the ON/Power LED keeps flashing, repeat the procedure, press the Stop/Reset/Resume/Cancel button 6 times.

Step 2: Reset the waste ink counter value to zero
- After the printer enters Service Mode, open the Service Tool. Use the Service Tool according to the printer model being repaired as shown in the list table below.

The following is a table of how to reset the printer by Manual method, General Tool and Service Tool, How to enter Service Mode, and Printer Service Manual (code and date) and a list of supported printers.

Canon S series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
S100	-	Manual	-	QY8-1378-000	June 12, 2001	S100, BJ S100, S100SP
S100SP	-	Manual	-	QY8-1378-000	June 12, 2001	S100, BJ S100, S100SP
S200	-	Manual	-	QY8-1380-000	Sept 28, 2001	S200, BJ S200, S200SP
S200SP	-	Manual	-	QY8-1380-000	Sept 28, 2001	S200, BJ S200, S200SP
S300	-	Manual	-	QY8-1377-000	-	S300, BJ S300
S520	2	Manual	-	QY8-1379-000	Dec 2001	i9100, S520, S750, S820, S820D, S820MG, S830D, S900, S9000
S600	2	Manual	-	QY8-1374-000	Jan 2001
S750	2	Manual	-	QY8-1379-000	Dec 2001	i9100, S520, S750, S820, S820D, S820MG, S830D, S900, S9000
S820	2	Manual	-	QY8-1379-000	Dec 2001	i9100, S520, S750, S820, S820D, S820MG, S830D, S900, S9000
S820D	2	Manual	-	QY8-1379-000	Dec 2001	i9100, S520, S750, S820, S820D, S820MG, S830D, S900, S9000
S820MG	2	Manual	-	QY8-1379-000	Dec 2001	i9100, S520, S750, S820, S820D, S820MG, S830D, S900, S9000
S830D	2	Manual	-	QY8-1379-000 QY8-1384-000	Dec 2001 May 27, 2002	i9100, S520, S750, S820, S820D, S820MG, S830D, S900, S9000
S900	2	Manual	-	QY8-1379-000	Dec 2001	i9100, S520, S750, S820, S820D, S820MG, S830D, S900, S9000
S9000	2	Manual	-	QY8-1379-000	Dec 2001	i9100, S520, S750, S820, S820D, S820MG, S830D, S900, S9000

Canon i series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
i70	3	Manual	-	QY8-1388-000	Oct 2001	i70, Pixus 50i
i80	3	Manual	-	QY8-1396-000	Feb 2004	i80, Pixus 80i
i250	2	-	GT v0.05	QY8-1389-000	June 2003	i250, i255, i350, i355, Pixus 350i
i255	2	-	GT v0.05	QY8-1389-000	June 2003	i250, i255, i350, i355, Pixus 350i
i320	2	-	GT v1.01	QY8-1383-000	Sept 2002	i320, Pixus 320i
i350	2	-	GT v0.05	QY8-1389-000	June 2003	i250, i255, i350, i355, Pixus 350i
i355	2	-	GT v0.05	QY8-1389-000	June 2003	i250, i255, i350, i355, Pixus 350i
i450	2	Manual	-	QY8-1386-010	May 7, 2003	i450, Pixus 450i
i470D	2	Manual	-	QY8-1387-000	Mar 2003	i470D, Pixus 470PD, i475D
i475D	2	Manual	-	QY8-1387-000	Mar 2003	i470D, Pixus 470PD, i475D
i550	2	Manual	-	QY8-1385-000	Sept 2002	i550, Pixus 550i, i850, Pixus 850i, i950, Pixus 950i
i560	2	Manual	-	QY8-1390-010	July 2003	i560, Pixus 560i
i850	2	Manual	-	QY8-1385-000	Sept 2002	i550, Pixus 550i, i850, Pixus 850i, i950, Pixus 950i
i860	2	Manual	-	QY8-1391-000	Augt 2003	i860, i865, Pixus 860i
i865	2	Manual	-	QY8-1391-000	Augt 2003	i860, i865, Pixus 860i
i6100	2	Manual	-	-	Mar, 2003	i6100, Pixus 6100i, i6500, Pixus 6500i
i6500	2	Manual	-	-	Mar, 2003	i6100, Pixus 6100i, i6500, Pixus 6500i
i900D	2	Manual	-	QY8-1394-000	Sept 2003	i900D, i905D, Pixus 900PD
i905D	2	Manual	-	QY8-1394-000	Sept 2003	i900D, i905D, Pixus 900PD
i950	2	Manual	-	QY8-1385-000	Sept 2002	i550, Pixus 550i, i850, Pixus 850i, i950, Pixus 950i
i960	2	Manual	-	QY8-1392-000	-	i960, i965
i965	2	Manual	-	QY8-1392-000	-	i960, i965
i9100	2	Manual	-	QY8-1379-000	Dec 2001	i9100, S520, S750, S820, S820D, S820MG, S830D, S900, S9000
i9900	2	Manual	-	QY8-1397-000	-	i9950, i9900, Pixus 9900i
i9950	2	Manual	-	QY8-1397-000	-	i9950, i9900, Pixus 9900i

Canon Pixus series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
Pixus 50i	3	Manual	-	QY8-1388-000	Oct 2001	i70, Pixus 50i
Pixus 80i	3	Manual	-	QY8-1396-000	Feb 2004	i80, Pixus 80i
Pixus 320i	2	-	GT v1.01	QY8-1383-000	Sept 2002	i320, Pixus 320i
Pixus 350i	2	-	GT v0.05	QY8-1389-000	June 2003	i250, i255, i350, i355, Pixus 350i
Pixus 450i	2	Manual	-	QY8-1386-010	May 7, 2003	i450, Pixus 450i
Pixus 470PD	2	Manual	-	QY8-1387-000	Mar 2003	i470D, Pixus 470PD, i475D
Pixus 550i	2	Manual	-	QY8-1385-000	Sept 2002	i550, Pixus 550i, i850, Pixus 850i, i950, Pixus 950i
Pixus 560i	2	Manual	-	QY8-1390-010	July 2003	i560, Pixus 560i
Pixus 850i	2	Manual	-	QY8-1385-000	Sept 2002	i550, Pixus 550i, i850, Pixus 850i, i950, Pixus 950i
Pixus 860i	2	Manual	-	QY8-1391-000	Augt 2003	i860, i865, Pixus 860i
Pixus 900PD	2	Manual	-	QY8-1394-000	Sept 2003	i900D, i905D/ Pixus 900PD
Pixus 950i	2	Manual	-	QY8-1385-000	Sept 2002	i550, Pixus 550i, i850, Pixus 850i, i950, Pixus 950i
Pixus 6100i	2	Manual	-	-	Mar, 2003	i6100, Pixus 6100i, i6500, Pixus 6500i
Pixus 6500i	2	Manual	-	-	Mar, 2003	i6100, Pixus 6100i, i6500, Pixus 6500i
Pixus 9900i	2	Manual	-	QY8-1397-000	-	i9950, i9900, Pixus 9900i
Pixus iP90	3	Manual	-	-	-	Pixma iP90, Pixus iP90
Pixus iP1500	2	-	GT v.1.18	QY8-1399-000	July 8, 2004	iP1500, Pixus iP1500
Pixus iP2200	2	-	GT v1.29	QY8-13AA-000	June 30, 2005	iP1200, iP1600, iP2200, Pixus iP2200
Pixus iP2500	2	-	GT v1.03	-	-	iP1100 / iP1180, iP1800 / iP1880, iP2500 / iP2580, Pixus iP2500
Pixus iP2600	2	-	ST a v.300 ST-a v.700	-	-	iP1100 / iP1180, iP1800 / iP1880, iP1900 / iP1980, iP2500 / iP2580, iP2600 / iP2680, Pixus iP2500, Pixus iP2600
Pixus iP3100	2	Manual	-	QY8-1398-000	Augt 2004	iP4000, Pixus iP3100, Pixus iP4100
Pixus iP4100	2	Manual	-	QY8-1398-000	Augt 2004	iP4000, Pixus iP3100, Pixus iP4100
Pixus iP4100R	2	Manual	-	QY8-13A3-000	-	Pixma iP4000R, Pixus iP4100R
Pixus iP6100D	2	Manual	-	QY8-13A6-000	Augt 2004	iP6000D, Pixus iP6100D
Pixus iP6600D	2	Manual	-	QY8-13AB-000	Augt 2005	iP6600D, iP6700D, Pixus iP6600D, Pixus iP6700D
Pixus iP6700D	2	Manual	-	QY8-13AB-000	Augt 2005	iP6600D, iP6700D, Pixus iP6600D/ Pixus iP6700D
Pixus iP7100	2	Manual	-	QY8-13A5-000	Augt 2004	iP8500, Pixus iP8600/iP8100/iP7100
Pixus iP8100	2	Manual	-	QY8-13A5-000	Augt 2004	iP8500, Pixus iP8600/iP8100/iP7100
Pixus iP8600	2	Manual	-	QY8-13A5-000	Augt 2004	iP8500, Pixus iP8600/iP8100/iP7100
Pixus MP600	2	Manual	-	QY8-13BD-000	Augt 20, 2006	MP600, MP600R, Pixus MP600
Pixus MP170	2	Manual	-	QY8-13AH-000	Augt 2008	MP170, Pixus MP170, MP450, Pixus MP450
Pixus MP280	5	-	ST v.1081	QY8-13CW-000	June 2010	MP280, MP287, MP288, Pixus MP280
Pixus MP450	2	Manual	-	QY8-13AH-000	Augt 2008	MP170, Pixus MP170, MP450, Pixus MP450
Pixus MP500	2	Manual	-	QY8-13AM-000	Augt 2005	MP500, Pixus MP500
Pixus MP610	2	Manual	-	QY8-13BJ-000	July 20, 2007	MP610, Pixus MP610
Pixus MP800	2	Manual	-	QY8-13AK-010	Feb 2006	Pixma MP800, MP800R, Pixus MP800
Pixus MP810	2	Manual	-	-	-	Pixma MP810, Pixus MP810, Pixma MP960, Pixus MP960
Pixus MP830	2	Manual	-	QY8-13AN-000	Feb 20, 2006	Pixma MP830, Pixus MP830
Pixus MP950	2	Manual	-	-	-	Pixma MP950, Pixus MP950
Pixus MP960	2	Manual	-	-	-	Pixma MP810, Pixus MP810, Pixma MP960, Pixus MP960
Pixus Pro9500	2	Manual	-	QY8-13AR-000	Apr 16, 2007	Pixma Pro9500, Pixus Pro9500

Canon iP series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
iP90	3	Manual	-	-	-	Pixma iP90, Pixus iP90
iP100	2	Manual	-	QY8-13BT-000	Mar 2008
iP110	5	-	ST v.4420	QY8-13ES-000	Oct 2014
iP1000	2	-	GT v1.07	QY8-13A2-010	June 18, 2004
iP1100 / iP1180	2	-	GT v1.03	-	-	iP1100 / iP1180, iP1800 / iP1880, iP2500 / iP2580, Pixus iP2500
iP1188	2	-	ST-s v1.20	QY8-13DQ-000	Feb 2012	Cannot be reset
iP1200	2	-	GT v1.29	QY8-13AA-000	June 30, 2005	iP1200, iP1600, iP2200, Pixus iP2200
iP1300	2	-	GT v1.00	-	-
iP1500	2	-	GT v.1.18	QY8-1399-000	July 8, 2004	iP1500, Pixus iP1500
iP1600	2	-	GT v1.29	QY8-13AA-000	June 30, 2005	iP1200, iP1600, iP2200, Pixus iP2200
iP1700	2	-	GT v1.00	-	-
iP1800 / iP1880	2	-	GT v1.03	-	-	iP1100 / iP1180, iP1800 / iP1880, iP2500 / iP2580, Pixus iP2500
iP1900 / iP1980	2	-	ST-a v.300 ST-a v.700	-	-	iP1100 / iP1180, iP1800 / iP1880, iP1900 / iP1980, iP2500 / iP2580, iP2600 / iP2680, Pixus iP2500, Pixus iP2600
iP2000	2	Manual	-	QY8-13A1-000	Augt 6, 2004
iP2200	2	-	GT v1.29	QY8-13AA-000	June 30, 2005	iP1200, iP1600, iP2200, Pixus iP2200
iP2500 / iP2580	2	-	GT v1.03	-	-	iP1100 / iP1180, iP1800 / iP1880, iP2500 / iP2580, Pixus iP2500
iP2600 / iP2680	2	-	ST-a v.300 ST-a v.700	-	-	iP1100 / iP1180, iP1800 / iP1880, iP1900 / iP1980, iP2500 / iP2580, iP2600 / iP2680, Pixus iP2500, Pixus iP2600
iP2700 series	5	-	ST v.1071	QY8-13CR-000	Jan 2010	iP2700, iP2702, iP2770, iP2772, iP2780, iP2788, Pixus iP2700
iP2800 series	5	-	ST v.4200	QY8-13EN-000	Dec 26, 2013	iP2800, iP2810, iP2820, iP2840, iP2845, iP2850, iP2855, iP2870, iP2872, iP2880, iP2890, iP2899
iP3000	2	Manual	-	QY8-13A0-000	July 13, 2004
iP3300	2	Manual	-	QY8-13AT-000 QY8-13AT-010	July 15, 2006 July 27, 2006	iP3300, iP3500
iP3500	2	Manual	-			iP3300, iP3500
iP3600 series	2	-	ST v.1030	QY8-13BW-000	Augt 2008	iP3600, iP3610, iP3620, iP3630, iP3640, iP3650, iP3660, iP3670, iP3680, Pixus iP3600
iP4000	2	Manual	-	QY8-1398-000	Augt 2004	iP4000, Pixus iP3100, Pixus iP4100
iP4000R	2	Manual	-	QY8-13A3-000	-	Pixma iP4000R, Pixus iP4100R
iP4200	2	Manual	-	QY8-13A9-000	July 20, 2005
iP4300	2	Manual	-	QY8-13BA-000	July 25, 2006
iP4500	2	Manual	-	QY8-13BI-000	July 12, 2007
iP4600 series	2	-	ST v.1030	QY8-13BY-000	July 25, 2008	Pixma iP4600, iP4680, Pixus iP4600
iP4700 series	2	-	ST v.1050	QY8-13CM-000	July 22, 2009	iP4700, iP4760, iP4780, Pixus iP4700
iP4800 series	5/6	-	ST v.1081	QY8-13CZ-000	Augt 2010	iP4800, iP4810, iP4820, iP4830, iP4840, iP4850, iP4860, iP4870, iP4880
iP4900 series	5	-	ST v.3000	QY8-13DH-000	June 2011	Pixma iP4900, iP4910, iP4920, iP4930, iP4940, iP4950, iP4970, iP4980, Pixus iP4900, iP4930
iP5000	2	Manual	-	-	-
iP5200 series	2	Manual	-	-	-	iP5200, iP5200R
iP5300	2	Manual	-	QY8-13BB-000	Augt 2006
iP6000D series	2	Manual	-	QY8-13A6-000	Augt 2004	iP6000D, Pixus iP6100D
iP6210D	2	Manual	-	-	-
iP6220D	2	Manual	-	QY8-13AD-000	Augt 2005
iP6310D	2	Manual	-	-	-
iP6320D	2	Manual	-	-	-
iP6600D	2	Manual	-	QY8-13AB-000	Augt 2005	iP6600D, iP6700D, Pixus iP6600D, Pixus iP6700D
iP6700D	2	Manual	-	QY8-13AB-000	Augt 2005	iP6600D, iP6700D, Pixus iP6600D, Pixus iP6700D
iP7200 series	5/6	-	ST. v.3400 ST. v.3400	QY8-13DZ-000 QY8-13DZ-040	Oct 20, 2012 June 20, 2014	iP7200, iP7210, iP7220, iP7230, iP7240, iP7250, iP7260, iP7270, iP7280
iP8500	2	Manual	-	QY8-13A5-000	Augt 2004	iP8500, Pixus iP8600
iP8700 series						iP8700, iP8720, iP8740, iP8750, iP8770

Canon MP series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
MP110	-	Manual	-	HY8-13A2-000	Nov 2004	MP110, MP130
MP130	-	Manual	-	HY8-13A2-000	Nov 2004	MP110, MP130
MP145 series	2	Manual	-			MP140, MP145
MP150	2	Manual	-	QY8-13AG-000 QY8-13AG-010	July 30, 2005 Jan 11, 2006
MP160	2	Manual	-	QY8-13AY-000 QY8-13AY-010	June 16, 2006 June 23, 2006
MP170 series	2	Manual	-	QY8-13AH-000	Augt 2008	MP170, MP178, Pixus MP170
MP180	2	Manual	-	QY8-13AX-000 QY8-13AX-010	June 16, 2006 June 23, 2006	MP180, MP460
MP190	2	Manual	-
MP210	2	Manual	-
MP220	-	Manual	-
MP230 series	5	-	ST v.3400	QY8-13DW-000	June 2012	MP230, MP235, MP236, MP237
MP240 series	2	-	ST v.1030	QY8-13BV-000	June 2008	MP240, MP245
MP250 series	2	-	ST v.1050	QY8-13CK-000	June 2009	MP250, MP258
MP259	2	-	ST v.1050	QY8-13DB-000	Sept 2010	MP259
MP260 series	2	-	ST v.1030	QY8-13BV-000	June 2008	MP260, MP268
MP270 series	2	-	ST v.1050	QY8-13CK-000	June 2009	MP270, MP276, Pixus MP270
MP280 series	5	-	ST v.1081	QY8-13CW-000	June 2010	MP280, MP287, MP288, Pixus MP280
MP320 series	2/3	-	ST v.1030	QY8-13CE-010	Dec 2008	MP320, MP328, MP330, MP338
MP330 series	2/3	-	ST v.1030	QY8-13CE-010	Dec 2008	MP320, MP328, MP330, MP338
MP360	-	Manual	-		Oct 24, 2003
MP370	-	Manual	-		Oct 24, 2003
MP390	-	Manual	-		Jan 7, 2004
MP450 series	2	Manual	-	QY8-13AH-000	Augt 2008	MP450, Pixus MP450
MP460	2	Manual	-	QY8-13AX-000 QY8-13AX-010	June 16, 2006 June 23, 2006	MP180, MP460
MP470, MP476	2	Manual	-
MP480 series	2	-	ST v.1030	QY8-13BV-000	June 2008	Pixma MP480, MP486, Pixus MP480
MP490, MP496	2	-	ST v.1050	QY8-13CK-000	June 2009	MP490, MP496, Pixus MP490
MP495, MP497, MP498	5	-	ST v.1081	QY8-13CW-000	June 2010	MP495, MP497, MP498
MP500	2	Manual	-	QY8-13AM-000	Augt 2005	MP500, Pixus MP500
MP510	2	Manual	-	QY8-13AZ-000	July 25, 2006
MP520	2	Manual	-	QY8-13BN-000	July 20, 2007
MP530	2	Manual	-	QY8-13AQ-000	Apr 20, 2006
MP540 series	2	-	ST v.1030	QY8-13CA-000	July 31, 2008	Pixma MP540, MP545, Pixus MP540
MP550 series	2	-	ST v.1050	QY8-13CL-000	Augt 20, 2009	MP550, MP558, Pixus MP550
MP560 series	2	-	ST v.1050	QY8-13CL-000	Augt 20, 2009	MP560, MP568
MP600 series	2	Manual	-	QY8-13BD-000	Augt 20, 2006	MP600, MP600R, Pixus MP600
MP610	2	Manual	-	QY8-13BJ-000	July 20, 2007	MP610, Pixus MP610
MP620 series	2	-	ST v.1030	QY8-13BZ-000	July 20, 2008	Pixma MP620, MP620B, MP628, Pixus MP620
MP630 series	2	-	ST v.1020	QY8-13CB-000	July 20, 2008	Pixma MP630, MP638, Pixus MP630
MP640 series	2	-	ST v.1050	QY8-13CN-000	Augt 20, 2009	MP640, MP640R, MP648, Pixus MP640
MP700	-	Manual	-	HY8-19B3-000	Apr 2003
MP730	-	Manual	-	HY8-19B3-000	Apr 2003
MP750	-	Manual	-	HY8-13A3-000	Nov 2004
MP760	-	Manual	-	HY8-13A4-000	Nov 2004
MP780	-	Manual	-	HY8-13A3-000	Nov 2004
MP800 series	2	Manual	-	QY8-13AK-010	Feb 2006	Pixma MP800, MP800R, Pixus MP800
MP810	2	Manual	-			Pixma MP810, Pixus MP810, Pixma MP960, Pixus MP960
MP830	2	Manual	-	QY8-13AN-000	Feb 20, 2006	Pixma MP830, Pixus MP830
MP950	2	Manual	-			Pixma MP950, Pixus MP950
MP960	2	Manual	-			Pixma MP810, Pixus MP810, Pixma MP960, Pixus MP960
MP970	2	Manual	-	QY8-13BP-000	Augt 20, 2007
MP980 series	2	-	ST v.1030	QY8-13BZ-000	July 20, 2008	Pixma MP980, MP988, Pixus MP980
MP990 series	2	-	ST v.1050			MP990, MP996, Pixus MP990

Canon MX series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
MX300 series	2	Manual	-	QY8-13BL-000	Augt 2007	MX300, MX308
MX310 series	2	Manual	-	QY8-13BH-000	Augt 2007	MX310, MX318
MX320 series	2	-	ST v.1030	QY8-13CE-010	Dec 2008	Pixma MX320, MX328
MX330 series	2	-	ST v.1030	QY8-13CE-010	Dec 2008	Pixma MX330, MX338
MX340 series	5/6	-	ST v.1071	QY8-13CS-000	Dec 2009	MX340, MX347, MX348
MX350 series	5/6	-	ST v.1071	QY8-13CS-000	Dec 2009	MX350, MX357, MX358, Pixus MX350
MX360 series	5/6	-	ST v.1074			MX360, MX366, MX368
MX370 series	5/6	-	ST v.3400	QY8-13DM-000	Feb 2011	MX370, MX371, MX372, MX374, MX375, MX376, MX377, MX378
MX390 series	5/6	-	ST v.3400			MX390, MX391, MX392, MX394, MX395, MX396, MX397, MX398
MX410 series	5/6	-	ST v.3400			MX410, MX411, MX412, MX414, MX416, MX418
MX420 series	5/6	-	ST v.3400			MX420, MX421, MX422, MX423, MX424, MX425, MX426, MX427, MX428
MX430 series	5/6	-	ST v.3400	QY8-13DM-000	Feb 2011	MX430, MX431, MX432, MX434, MX435, MX436, MX437, MX438
MX450 series	5/6	-	ST v.3400			MX450, MX451, MX452, MX454, MX455, MX456, MX457, MX458
MX470 series	5/6	-	ST v.4200	QY8-13EK-000	Dec 2013	MX470, MX471, MX472, MX474, MX475, MX476, MX477, MX478
MX490 series	5/6	-	ST v.4610	QY8-13ET-000	Jan 20, 2015	MX490, MX491, MX492, MX494, MX495, MX496, MX497, MX498, MX499
MX510 series	5/6	-	ST v.3400	QY8-13DM-000	Feb 2011	MX510, MX511, MX512, MX513, MX514, MX515, MX516, MX517, MX518
MX520 series	5/6	-	ST v.3400			MX520, MX521, MX522, MX523, MX524, MX525, MX526, MX527, MX528
MX530 series	5/6	-	ST v.4200	QY8-13EK-000	Dec 2013	MX530, MX531, MX532, MX534, MX535, MX536, MX537, MX538
MX700	2	Manual	-	QY8-13BM-000	Augt 20, 2007
MX710 series						MX710, MX711, MX712, MX713, MX714, MX715, MX716, MX717, MX718
MX720 series	5	-	ST v.3600	QY8-13EG-000	Feb 20, 2013	MX720, MX728
MX850	2	Manual	-	QY8-13BR-000	Jan 20, 2008
MX860 series	2	-	ST v.1030	QY8-13CF-000	Jan 20, 2009	Pixma MX860, MX868, Pixus MX860
MX870 series	5/6	-	ST v.1072			MX870, MX876, Pixus MX870
MX880 series	5/6	-	ST v.2000	QY8-13DF-000	Jan 20, 2011	MX880, MX882, MX883, MX884, MX885, MX886, MX888
MX890 series						MX890, MX891, MX892, MX893, MX894, MX895, MX897, MX898
MX920 series	5	-	ST v.3600	QY8-13EG-000	Feb 20, 2013	Pixma MX920, MX928, Pixus MX920, MX923
MX7600	2	Manual	-	QY8-13BU-000	Mar 20, 2008

Canon MG series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
MG2100 series	5/6	-	ST v.3000	QY8-13DL-000	Augt 26, 2011	Pixma MG2100, MG2110, MG2120, MG2130, MG2140, MG2150, MG2160, MG2170, MG2180, Pixus MG2100, MG2130
MG2200 series	5/6	-	ST v.3400 ST v.3400	QY8-13DL-010 QY8-13DL-020	June 1, 2012 Apr 17, 2013	MG2200, MG2210, MG2220, MG2240, MG2250, MG2260, MG2270
MG2400 series	5/6	-	ST v.3800	QY8-13EH-000	July 2013	MG2400, MG2410, MG2420, MG2430, MG2440, MG2450, MG2460, MG2470, MG2490
MG2500 series	5/6	-	ST v.3800	QY8-13EH-000	July 2013	MG2500, MG2510, MG2520, MG2530, MG2540, MG2550, MG2560, MG2570, MG2580, MG2590
MG2900 series	5/6	-	ST v.4502	QY8-13ER-000	June 12, 2014	MG2900, MG2910, MG2920, MG2924, MG2930, MG2940, MG2950, MG2960, MG2970, MG2980, MG2990
MG3000 Series						MG3000, MG3010, MG3020, MG3022, MG3040, MG3050, MG3051, MG3052, MG3053, MG3060, MG3070, MG3070S, MG3077, MG3077S, MG3080, MG3090
MG3100 series	5/6	-	ST v.3000	QY8-13DL-000	Augt 26, 2011	Pixma MG3100, MG3110, MG3120, MG3130, MG3140, MG3150, MG3160, MG3170, MG3180, Pixus MG3100, MG3130
MG3200 series	5/6	-	ST v.3400 ST v.3400	QY8-13DL-010 QY8-13DL-020	June 1, 2012 Apr 17, 2013	MG3200, MG3210, MG3220, MG3230, MG3240, MG3250, MG3260, MG3270
MG3500 series	5/6	-	ST v.3900 ST v.4713	QY8-13EH-000 QY8-13EH-010	June 20, 2013 May 8, 2015	MG3500, MG3510, MG3520, MG3530, MG3540, MG3550, MG3560, MG3570, MG3580
MG3600 series	5/6	-	ST v.4713	QY8-13EH-010	May 8, 2015	MG3600, MG3610, MG3620, MG3630, MG3640, MG3650, MG3660, MG3670, MG3680, MG3690
MG4100 series	5/6	-	ST v.3000	QY8-13DL-000	Augt 26, 2011	Pixma MG4100, MG4110, MG4120, MG4130, MG4140, MG4150, MG4160, MG4170, MG4180, Pixus MG4100, MG4130
MG4200 series	5/6	-	ST v.3400 ST v.3400	QY8-13DL-010 QY8-13DL-020	June 1, 2012 Apr 17, 2013	MG4200, MG4210, MG4220, MG4230, MG4240, MG4250, MG4260, MG4270, MG4280
MG5100 series	5/6	-	ST v.1081	QY8-13CX-000	July 2010	MG5100, MG5110, MG5120, MG5140, MG5150, MG5160,  MG5170, MG5180, Pixus MG5130
MG5200 series	5/6	-	ST v.1081	QY8-13DC-000	Augt 20, 2010	MG5200, MG5210, MG5220, MG5230, MG5240, MG5250, MG5260, MG5270, MG5280, Pixus MG5200, MG5230
MG5300 series	5/6	-	ST v.3000	QY8-13DI-000	June 2011	Pixma MG5300, MG5310, MG5320, MG5330, MG5340, MG5350, MG5360, MG5370, MG5380, Pixus MG5300, MG5330
MG5400 series	5/6	-	ST v.3400 ST v.3400	QY8-13DZ-000 QY8-13DZ-040	Oct 20, 2012 June 20, 2014	MG5400, MG5410, MG5420, MG5430, MG5440, MG5450, MG5460, MG5470, MG5480, MG5490
MG5500 series	5/6	-	ST v.4712	QY8-13EJ-000 QY8-13EJ-010 QY8-13EJ-020 QY8-13EJ-030	June 2013 June 2014 Oct 2014 June 2015	MG5500, MG5510, MG5520, MG5530, MG5540, MG5550, MG5560, MG5570, MG5580
MG5600 series	5/6	-	ST v.4712	QY8-13EJ-010 QY8-13EJ-020 QY8-13EJ-030	June 2014 Oct 2014 June 2015	MG5600, MG5610, MG5620, MG5630, MG5640, MG5650, MG5655, MG5660, MG5670, MG5680
MG5700 series	5/6	-	ST v.4712	QY8-13EJ-030	June 2015	MG5700, MG5710, MG5720, MG5721, MG5730, MG5740, MG5750, MG5751, MG5752, MG5753, MG5760, MG5765, MG5766, MG5770, MG5780, MG5790, MG5795
MG6100 series	5/6	-	ST v.1081	QY8-13DA-000	Augt 20, 2010	MG6100, MG6110, MG6120, MG6130, MG6140, MG6150, MG6160, MG6170, MG6180, Pixus MG6100, MG6130
MG6200 series	5/6	-	ST v.3000	QY8-13DJ-000	July 2011	Pixma MG6200, MG6210, MG6220, MG6230, MG6240, MG6250, MG6260, MG6270, MG6280, Pixus MG6200, MG6230
MG6300 series	5/6	-	ST v.3400 ST v.3400	QY8-13DZ-000 QY8-13DZ-040	Oct 20, 2012 June 20, 2014	MG6300, MG6310, MG6320, MG6330, MG6340, MG6350, MG6360, MG6370, MG6380, MG6390
MG6400 series	5/6	-	ST v.4712	QY8-13EJ-000 QY8-13EJ-010 QY8-13EJ-020 QY8-13EJ-030	July 2013 June 2014 Oct 2014 June 2015	MG6400, MG6410, MG6420, MG6440, MG6450, MG6451, MG6460, MG6470
MG6530	5/6	-	ST v.3400	QY8-13DZ-040	June 20, 2014
MG6600 series	5/6	-	ST v.4712	QY8-13EJ-010 QY8-13EJ-020 QY8-13EJ-030	June 2014 Oct 2014 June 2015	MG6600, MG6610, MG6620, MG6640, MG6650, MG6660, MG6670, MG6680
MG6730	5/6	-	ST v.3400	QY8-13DZ-040	June 20, 2014
MG6800 series	5/6	-	ST v.4712	QY8-13EJ-030	June 2015	MG6800, MG6810, MG6820, MG6821, MG6822, MG6840, MG6850, MG6851, MG6852, MG6853, MG6860, MG6865, MG6866, MG6870, MG6880
MG6900
MG7100 series	5/6	-	ST v.3400	QY8-13DZ-040	June 20, 2014	MG7100, MG7110, MG7120, MG7130, MG7140, MG7150, MG7160, MG7170, MG7180, MG7190
MG7500 series	5/6	-	ST v.3400	QY8-13DZ-040	June 20, 2014	MG7500, MG7510, MG7520, MG7530, MG7540, MG7550, MG7560, MG7570, MG7580, MG7590
MG7700 Series
MG8100 series	5/6	-	ST v.1081	QY8-13CY-000	Augt 20, 2010	MG8100, MG8110, MG8120, MG8130, MG8140, MG8150, MG8160, MG8170, MG8180, Pixus MG8130
MG8200 series	5/6	-	ST v.3000	QY8-13DK-000	July 2011	Pixma MG8200, MG8210, MG8220, MG8230, MG8240, MG8250, MG8260, MG8270, MG8280, Pixus MG8200, MG8230

Canon iX series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
iX4000	2	Manual	-	QY8-13AP-000	Feb 2006	iX4000, iX5000
iX5000	2	Manual	-	QY8-13AP-000	Feb 2006	iX4000, iX5000
iX6500 series	5	-	ST v.2000	QY8-13DG-000	Mar 20, 2011	iX6500, iX6510, iX6520, iX6540, iX6550, iX6560, iX6570, iX6580, Pixus iX6530
iX6700 series						iX6700, iX6730, iX6750, iX6770
iX6800 series						iX6800, iX6820, iX6840, iX6850, iX6870
iX7000	2	-	ST v.1050	QY8-13CJ-000	Augt 31, 2009	Pixma iX7000, Pixus iX7000

Canon E series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
E400
E460 series	5/6	-	ST v.4502	QY8-13ER-000	June 12, 2014	E460, E461, E462, E463, E464, E465, E466, E467, E468
E480 series	5/6	-	ST v.4610	QY8-13ET-000	Jan 20, 2015	E480, E481, E482, E483, E484, E485, E486, E487, E488, E489
E500	5/6	-	ST v.3000		June 2012	Pixma E500
E510	5/6	-	ST v.3400		June 2012	Pixma E500, E510, E518
E518	5/6	-	ST v.3400		June 2012	Pixma E500, E510, E518
E560
E568
E600
E608
E610
E618

Canon G series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
G1000 series	5/6	-	ST v.4718	QY8-13EX-000 QY8-13EX-010 QY8-13EX-020 QY8-13EX-030 QY8-13EX-040	Oct 2015 Nov 2015 Jan 2016 Sept 2016 Mar 2017	G1000, G1100, G1200, G1400, G1500, G1800, G1900
G2000 series	5/6	-	ST v.4718	QY8-13EX-000 QY8-13EX-010 QY8-13EX-020 QY8-13EX-030 QY8-13EX-040	Oct 2015 Nov 2015 Jan 2016 Sept 2016 Mar 2017	G2000, G2002, G2100, G2200, G2400, G2500, G2600, G2800, G2900
G3000 series	5/6	-	ST v.4718	QY8-13EX-000 QY8-13EX-010 QY8-13EX-020 QY8-13EX-030 QY8-13EX-040	Oct 2015 Nov 2015 Jan 2016 Sept 2016 Mar 2017	G3000, G3100, G3102, G3200, G3400, G3500, G3600, G3800, G3900
G4000 series	5/6	-	ST.v4904	QY8-13FD-000 QY8-13FD-010	Oct 2016 Mar 2017	G4000, G4100, G4102, G4200, G4300 G4400, G4500, G4600, G4800, G4900
G5000, G5240

Canon PRO series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
PRO-1	5	-	ST v.3000	QY8-13DE-000	Sept 30, 2011
PRO-10, PRO-10S	5	-	ST v.3400	QY8-13EA-000	Sept 20, 2012
PRO-100, PRO-100S	5	-	ST v.3400	QY8-13EA-000	Sept 20, 2012
PRO-500	5	-	ST v.4718	QY8-13EZ-000	Oct 20, 2015
PRO-1000	5	-	ST v.4718	QY8-13EZ-000	Oct 20, 2015
Pro9000	2	Manual	-
Pro9000 Mark II	2	-	ST v.1030	QY8-13CH-000	Mar 15, 2009
Pro9500	2	Manual	-	QY8-13AR-000	Apr 16, 2007	Pixma Pro9500, Pixus Pro9500
Pro9500 Mark II	2	-	ST v.1030	QY8-13CI-000	Mar 15, 2009

Canon TS series

• Enter service mode Time(s): press the Stop/Reset/Resume/Cancel button x times.
• How to reset: Manual / General Tool / Service Tool (read the description above).
• Service Manual Documents: Manual code and manual date.
• Supported printers: Service Manual is used for printers.
• Link to download tool: Canon Service Tool Version

Printer Series	Enter Service Mode Time(s)	How to Reset		Service Manual Document		Supported printers
		Manual Reset	General Tool / Service Tool	Manual Code	Manual Date
TS6000 series	5/6	-		QY8-13FB-010	July 20, 2017	TS6000, TS6010, TS6020, TS6030, TS6040, TS6050, TS6060, TS6070, TS6080, TS6090
TS6100 series	5/6	-		QY8-13FB-010	July 20, 2017	TS6100, TS6110, TS6120, TS6130, TS6140, TS6150, TS6160, TS6170, TS6180, TS6190
TS8000 series	5/6	-		QY8-13FB-010	July 20, 2017	TS8000, TS8010, TS8020, TS8030, TS8040, TS8050, TS8060, TS8070, TS8080, TS8090
TS8100 series	5/6	-		QY8-13FB-010	July 20, 2017	TS8100, TS8110, TS8120, TS8130, TS8140, TS8150, TS8160, TS8170, TS8180, TS8190
TS9000 series	5/6	-		QY8-13FB-010	July 20, 2017	TS9000, TS9010, TS9020, TS9030, TS9040, TS9050, TS9060, TS9070, TS9080, TS9090
TS9100 series	5/6	-		QY8-13FB-010	July 20, 2017	TS9100, TS9110, TS9120, TS9130, TS9140, TS9150, TS9160, TS9170, TS9180, TS9190

Questions and Answers

Q: The printer printout is bad, is the print head clogged/damaged, should I replace the cartridge?

A: A complete discussion regarding this issue, please read Troubleshooting Canon printer poor printouts

Q: Where can I download the Service Tool?

A: Although the data we have is not complete and not all of our Service Tools are available, the file links for the General Tool and Service Tool in the table above, you can find in the Canon Service Tool Version

Q: Can a certain type of printer be reset with a different Service Tool? Example: Canon MG2100 series. In the table mentioned to reset, use ST v.3000. Can ST v.3400 be used to reset Canon MG2100 series?

A: It says in Service Manual with code

-   QY8-13DL-000 (Aug 26, 2011) for Canon MG2100 series, MG3100 series, MG4100 series (New edition.)

-   QY8-13DL-010 (June 1, 2012) for Canon MG2100 series, MG3100 series, MG4100 series, and 2012 2H models (MG2200 series, MG3200 series, MG4200 series) added.

-   QY8-13DL-020 (Apr 17, 2013) for Canon MG2100 series, MG3100 series, MG4100 series, and 2012 2H models (MG2200 series, MG3200 series, MG4200 series) added.

To reset the printer, it says in the Service Manual

-   QY8-13DL-000 to reset use ST v.3000

-   QY8-13DL-010 to reset use ST v.3400

-   QY8-13DL-020 to reset use ST v.3400

From the information in the Service Manual document above, to reset

-   Canon MG2100 series, can use ST v.3000 or ST v.3400.

-   Canon MG3100 series, can use ST v.3000 or ST v.3400.

-   Canon MG4100 series, can use ST v.3000 or ST v.3400.

-   Canon MG2200 series, use ST v.3400.

-   Canon MG3200 series, use ST v.3400.

-   Canon MG4200 series, use ST v.3400.

or the above information can be written:

-    ST v.3000 supports printers: Canon MG2100 series, MG3100 series, MG4100 series, while

-    ST v.3400 supports printers: Canon MG2100 series, MG2200 series, MG3100 series, MG3200 series, MG4100 series, MG4200 series.

To find the correct information regarding the Service Tool that is suitable for your printer, all you have to do is find the Service Manual of the printer being repaired. In the Service Manual you will find information on how to reset the printer and what Service Tool to use.

Q: In the table there are several Service Tools that are not available on the internet, such as:

-  Service Tool v.3800 for Canon MG2400 series, MG2500 series

-  Service Tool v.4200 for Canon iP2800 series, MX470 series, MX530 series

-  Service Tool v.4420 for Canon iP110

-  Service Tool v.4502 for Canon MG2900 series, E460 series

-  Service Tool v.4610 for Canon MX490 series, E480 series

-  Service Tool v.4712 for Canon MG5500 series, MG5600 series, MG5700 series, MG6400 series, MG6600 series, MG6800 series

-  Service Tool v.4713 for Canon MG3500 series, MG3600 series

What should I do?

A: The table above we created refers to the information contained in the Service Manual document that we found, as well as the Service Tool. Based on the information we found, here is a list of Service Tools for Canon printers.

Name	Estimated Month of Service Tool Release	Is this Service Tool available on the internet?	Price		Is there a Service Manual document that mentions this tool?
			Free	Paid
Service Tool-a v3.00	February 2008	Yes	Free	-	No
Service Tool v.1020	March 2008	Yes	Free	-	Yes
Service Tool-a v7.00	June 2008	Yes	Free	-	No
Service Tool v.1030	March 2009	Yes	Free	-	Yes
Service Tool v.1050	June 2009	Yes	Free	-	Yes
Service Tool v.1071	December 2009	No	-	-	Yes
Service Tool v.1072	January 2010	No	-	-	Yes
Service Tool v.1073	February 2010	No	-	-	No
Service Tool v.1074	March 2010	Yes	Free	-	Yes
Service Tool v.1081	June 2010	No	-	-	Yes
Service Tool v.2000	September 2010	Yes	Free	-	Yes
Service Tool v.3000	June 2011	Yes	Free	-	Yes
Service Tool v.3200	June 2011	Yes	Free	-	No
Service Tool v.3400	February 2012	Yes	Free	-	Yes
Service Tool v.3600	February 2013	Yes	Free	-	Yes
Service Tool v.3800	July 2013	No	-	-	Yes
Service Tool v.3900	July 2013	Yes	-	Paid	No
Service Tool v.4100	September 2013	No	-	-	No
Service Tool v.4200	December 2013	No	-	-	Yes
Service Tool v.4420	July 2014	No	-	-	Yes
Service Tool v.4421	July 2014	No	-	-	No
Service Tool v.4502	-	No	-	-	Yes
Service Tool v.4610	January 2015	No	-	-	Yes
Service Tool v.4620	February 2015	No	-	-	No
Service Tool v.4710	-	No	-	-	Yes
Service Tool v.4712	June 2015	No	-	-	Yes
Service Tool v.4713	June 2015	No	-	-	Yes
Service Tool v.4718	July 2015	Yes	Free	-	Yes
Service Tool v.4720	February 2016	Yes	Free	-	No
Service Tool v.4904	June 2016	Yes	-	Paid	No
Service Tool v.4905	September 2016	Yes	-	Paid	No
Service Tool v.4906	September 2016	Yes	-	Paid	No
Service Tool v.4907	February 2017	Yes	-	Paid	No
Service Tool v.5006	July 2017	Yes	-	Paid	No
Service Tool v.5007	August 2017	Yes	-	Paid	No
Service Tool v.5103	November 2017	Yes	-	Paid	No
Service Tool v.5105	-	Yes	-	Paid	No
Service Tool v.5204	June 2018	Yes	-	Paid	No
Service Tool v.5301	-	Yes	-	Paid	No
Service Tool v.5306	-	Yes	-	Paid	No
Service Tool v.5405	-	Yes	-	Paid	No
Service Tool v.5406	-	Yes	-	Paid	No
Service Tool v.5510	-	Yes	-	Paid	No

Table Description

• Estimated Month of Service Tool Release

The Service Manual does not mention the exact date of a Service Tool being released. This column contains the estimated month and year of Service Tool release, based on information we have gathered from various sources on the internet.

• Is this Service Tool available on the internet?

Unfortunately not all Service Tools can be downloaded on the internet. Service Manual and Service Tool are Canon printer repair tools that are confidential and are used on a limited basis by Canon Service Centers. We only collect data on the internet, then summarize it into a table, making it easy to analyze. If the column says:

"Yes" means this Service Tool is on the internet, and can be downloaded for "Free" or there are other parties who sell it.

"No" means that this Service Tool is not available on the internet, or cannot be downloaded for free or that no other party is selling it.

• Is there a Service Manual document that mentions this tool?

Based on the Service Manual data that we have, if it is written in the column:
"Yes" means that there is a Service Manual document that mentions the tool.
"No" means that there is no Service Manual document that mentions the tool, or we don't have a Service Manual document that mentions the tool. This happens because the number of Service Manuals on the internet is very limited.

Here is the information regarding the Service Tool mentioned above.

• Service Tool v.3800. The download link for this tool does not exist on the internet either for free or paid, and we cannot confirm that Service Tool v.3900 or later version can be used instead of Service Tool v.3800
• Service Tool v.4200, v.4420, v.4502, v.4610. The download link for this tool does not exist on the internet either for free or paid, and we cannot confirm that Service Tool v.4718, v.4720 or later version can be used instead of Service Tool v.4200, v.4420, v.4502, v.4610.
• Service Tool v.4712, v.4713. Because these two tools are still included in Service Tool v.47xx, for Service Tool v.4710, v.4712, v.4713, instead use Service Tool v.4718 or v.4720.

Q: In the table there are several columns whose data is empty. What really happened?

A: We collect Service Manual (pdf) and Parts Catalog (pdf) for Canon printers, and summarize them in a table. Unfortunately we don't have all Service Manuals for Canon printers. We will continue to try to find the Service Manual document, and if there is an update to our data, we will automatically complete the table above. If you have Service Manual and Parts Catalog documents, and want to share them with us, please send an email to gpsbjnno11@gmail.com

Q: My printer has an error and needs to be reset. I don't know which Service Tool is suitable for my printer. What should I do?

A: If your printer is not in the table above, and you don't know what Service Tool supports your printer, for consideration is that you must know the month and year of your printer's release. Example: If your printer was released in August 2016, it is likely that the Service Tool that supports your printer is Service Tool v.49xx.
